NP7287XGS is a high-performance XGS-PON ONT that provides ultra-fast data, voice, and video services for individual users, SOHO, and small businesses. Designed with intelligent routing capabilities, it enables users to easily manage bandwidth allocation, control the number of connected devices, and monitor network activity, ensuring a smooth and efficient broadband experience.
|
Wireless Standards |
IEEE802.11a/n/ac/ax/be @5GHz, IEEE802.11b/g/n/ax/be @2.4GHz |
|
Signal Rate |
5GHz (4x4): Up to 5764Mbps, 2.4GHz (4x4): Up to 1376Mbps |
|
Interface |
1 x SC/APC PON Port 4 x 10/100/1000 Mbps LAN Ports 1 x 10 Gbps LAN port 1 x USB3.0 Port 1 x FXS Port 1 x DC Port |
|
Power Supply |
DC 12V3A |
|
Antenna |
4 x 3dBi Dualband internal antennas 1 x 3dBi 2.4G DFS internal antenna 1 x 3dBi 5G coverage internal antenna |
|
Dimensions |
71mm*174mm*225mm(W*D*H) |
|
Operating Temperature |
0 ℃~40 ℃ |
|
WAN Type |
Dynamic IP/ Static IP/ PPPoE |
|
Internet Protocol |
IPv4, IPv6 |
|
Firewall Security |
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding |
|
VOIP Features |
One RJ-11 FXS port for connecting to analog telephones, Call forwarding, Call waiting, Call block, 3-way conference call |
|
Management |
Access Control, Local Management, Remote Management |
|
Standard Packing List |
1 x Power Adaptor |
|
1 x NP7287XGS |
|
|
1 x Ethernet Cable |
